Motorola XPR 7580e

SKU: AAH56UCN9RB1AN-UL

Price:
Add to cart or Log In to view price
Shop accessories

NOTICE - Limited stock and longer than normal delivery times

We have limited stock of this item, and the manufacturer is estimating lengthy lead times. When you place an order, your payment method will be charged and your funds will hold your place in line. We fulfill backorders on a first in, first out basis.

If you need something quickly, please contact our team to discuss alternative options.

Description

This radio has been discontinued by Motorola. The replacement model is the Motorola R7.

The Motorola XPR 7580e radio is a 1000 channel handheld unit that is ideal for public safety, oil and gas, mining, and manufacturing industries. The XPR 7580e transmits using digital 800/900 MHz frequencies.

Thinking about upgrading to the XPR7580e from a Motorola XPR6000 series radio?

View a PDF detailing the differences between the two generations.

Motorola XPR7580e radio highlights

  • Digital and analog transmissions
  • 1000 channels
  • 800 and 900 MHz frequency bands
  • 2.5 watts max power out
  • IP68 water and dust proof
  • 21 hours of battery life and up to 28 with hi-cap battery
  • Full color display w/full keypad
  • Orange dedicated emergency button
  • Intrinsically safe option (UL) available
  • 5 year Motorola warranty

Model numbers

800/900 MHz Capable - AAH56UCN9WB1AN
800/900 MHz Enabled - AAH56UCN9RB1AN

Supported system technologies

  • Conventional analog/digital
  • IP site connect
  • Capacity plus
  • Linked capacity plus
  • Connect plus (enabled version)
  • Capacity max (enabled version)
  • Wave OnCloud

Included XPR 7580e accessories

Shop all XPR 7580e radio accessories

800/900 MHz Antenna
Capable Battery PMNN4491
Enabled Battery PMNN4493
Belt Clip PMLN7008
Charger PMPN4174
Accessory Cover 15012157001

Resources

Motorola radios similar to the XPR 7580e

If you aren't sure if the XPR 7580e radio is the right fit, check out our recommended alternatives.


    Free Motorola XPR 7580e radio programming with purchase

    Motorola XPR 7580e radio range

    Flat open terrain

    2 - 3 miles

    Suburban areas 1 - 2 miles
    Urban areas 1 - 2 miles
    Inside buildings

    30 - 40 floors

    These are estimates based on the XPR7580e radio using standard accessories at full power, many factors affect range.

    Motorola XPR 7580e specifications

    Dimensions (H x W x D)
    5.1 x 2.2 x 1.4 in.
    Weight w/capable battery11 oz.
    Weight w/enabled battery12 oz.
    Programmable buttons
    5
    Emergency buttonYes, orange
    User programmable?
    No, requires dealer support
    DurabilityIP68 water/dust proof
    Mil spec: 810 D, 810 E

    Performance data

    Frequency range800 MHz (806-825/851-870 MHz)
    900 MHz (896-902/935-941 MHz)
    Max Power output2.5 Watts
    Coverage areaAdjustable power output for varying coverage
    Repeater capableYes
    Estimated battery life19 hours (Capable)
    28 hours (Enabled)
    Capable batteryPMNN4491 Li-ion
    Capable battery size2100 mAh
    Enabled batteryPMNN4493 Li-ion
    Enabled battery size3000 mAh
